Catalyst switches
Cisco Catalyst 9300 24-port 10G/mGig with modular uplink, UPOE+, Network Advantage
VPN# C9300X-24HX-1A
Available to order · ships in ~1–2 weeks
Pre-tax. GPC accepted; ask about volume and emergency-acquisition pricing.
- Product Type
- Ethernet Switch
- Manageable
- Yes
- Ethernet Technology
- 10 Gigabit Ethernet
- Product Family
- Catalyst 9300
- Stack Port
- Yes
- Media Type Supported
- Twisted Pair
- Total Number of Network Ports
- 24
- Environmental Compliance
- Restriction of Hazardous Substances (RoHS)
- Government Purchase Card (GPC) accepted
- TAA-compliant & government contract-vehicle ready
Overview
Cisco Catalyst 9300 24-port 10G/mGig with modular uplink, UPOE+, Network Advantage - 24 Ports - Manageable - 10 Gigabit Ethernet - 10/100/1000Base-T, 10GBase-T - 2 Layer Supported - Modular - 1100 W Power Consumption - 735 W PoE Budget - Twisted Pair - Rack-mountable, Standalone - Lifetime Limited Warranty (part number C9300X-24HX-1A) is supplied by Uniqcli, an authorized Cisco partner, in the Cisco Switches & Bridges category. Network Technology: 10/100/1000Base-T, 10GBase-T.
24 Ports - Manageable - 10 Gigabit Ethernet - 10/100/1000Base-T, 10GBase-T - 2 Layer Supported - Modular - 1100 W Power Consumption - 735 W PoE Budget - Twisted Pair - Rack-mountable, Standalone - Lifetime Limited Warranty
• Effectively increases available bandwidth on your network • Conveniently lets you connect two standard Ethernet ports to ensure maximum efficiency • Provides efficient communication with other ethernet switch in the stack to ensure maximum productivity • Features 24 networking ports to meet the requirements of the most demanding workgroups • With leading Layer 2 support, experience enhanced convenience, secure business operations, and a borderless network experience
Key specifications: Network Technology: 10/100/1000Base-T, 10GBase-T · Ethernet Technology: 10 Gigabit Ethernet · Media Type Supported: Twisted Pair · Limited Warranty: Lifetime · Layer Supported: 2 · Networking Standards: IEEE 802.3ac, IEEE 802.3bt, IEEE 802.1BA, IEEE 802.1ae, IEEE 802.1s, IEEE 802.1w, IEEE 802.1p, IEEE 802.11ac, IEEE 802.1AVB, IEEE 802.1x, IEEE 802.3af, IEEE 802.3at · Manageable: Yes · Modular: Yes.
TAA-compliant and GPC-payable. Request a quote for current pricing, stock, and lead time.
Highlights
- Effectively increases available bandwidth on your network
- Conveniently lets you connect two standard Ethernet ports to ensure maximum efficiency
- Provides efficient communication with other ethernet switch in the stack to ensure maximum productivity
- Features 24 networking ports to meet the requirements of the most demanding workgroups
- With leading Layer 2 support, experience enhanced convenience, secure business operations, and a borderless network experience
- Rack mounting enables you to organize wires & secure cables for professional installation
- Management capability provides control over setup and configuration of your network
- Optimize the performance of business networks with 10 Gigabit Ethernet connectivity
- Government Purchase Card (GPC) accepted
Cisco Cisco Catalyst 9300 24-port 10G/mGig with modular uplink, UPOE+, Network Advantage - 24 Ports - Manageable - 10 Gigabit Ethernet - 10/100/1000Base-T, 10GBase-T - 2 Layer Supported - Modular - 1100 W P datasheet & specifications
Media & Performance
- Network Technology
- 10/100/1000Base-T, 10GBase-T
- Ethernet Technology
- 10 Gigabit Ethernet
- Media Type Supported
- Twisted Pair
Warranty
- Limited Warranty
- Lifetime
Network & Communication
- Layer Supported
- 2
- Networking Standards
- IEEE 802.3ac, IEEE 802.3bt, IEEE 802.1BA, IEEE 802.1ae, IEEE 802.1s, IEEE 802.1w, IEEE 802.1p, IEEE 802.11ac, IEEE 802.1AVB, IEEE 802.1x, IEEE 802.3af, IEEE 802.3at
Management & Protocols
- Manageable
- Yes
Interfaces/Ports
- Modular
- Yes
- Uplink Port
- Yes
- Stack Port
- Yes
- Total Number of Network Ports
- 24
- Port/Expansion Slot Details
- 24 x 10 Gigabit Ethernet PoE+
Power Description
- Input Voltage
- 120 V AC, 230 V AC
- Power Source
- Power Supply, AC
- PoE Budget
- 735 W W
- Power Consumption
- 1100 W W
Miscellaneous
- Environmentally Friendly
- Yes
- Environmental Compliance
- Restriction of Hazardous Substances (RoHS), Waste Electrical and Electronic Equipment Directive (WEEE)
Physical Characteristics
- Form Factor
- Rack-mountable, Standalone
- Weight (Approximate)
- 13.80 lb g
- Height
- 1.7" mm
- Width
- 17.5" mm
- Depth
- 17.5" mm
General Information
- Product Type
- Ethernet Switch
- Product Model
- C9300X-24HX
- Product Series
- 9300
Documents & datasheets
Free download — tell us where to send it.
- Document (PDF)
Official Cisco datasheet
Full specifications, port maps, power draw, and ordering details for this platform. Add your name and work email and the datasheet opens right here in our viewer.
Frequently asked questions
How much does the Cisco Catalyst 9300 24-port 10G/mGig with modular uplink, UPOE+, Network Advantage - 24 Ports - Manageable - 10 Gigabit Ethernet - 10/100/1000Base-T, 10GBase-T - 2 Layer Supported - Modular - 1100 W P (C9300X-24HX-1A) cost?
Uniqcli sells the C9300X-24HX-1A for $13,706.68 against a Cisco list price of $20,198.96. Add it to your cart and submit to confirm current pricing, stock, and lead time. Lower pricing is available for volume orders, Government Purchase Card (GPC) buys, and emergency or urgent acquisitions. Free US shipping on orders over $2,500.00.
Is the C9300X-24HX-1A TAA compliant and available for government and DoD buyers?
Often yes — it depends on the unit. Cisco manufactures the C9300X-24HX-1A in several countries, so Trade Agreements Act (TAA) status varies by production lot. Uniqcli is an authorized Cisco partner: we confirm the country of origin before shipment, and if a given C9300X-24HX-1A is not TAA-designated, we will source a TAA-certified equivalent of the same model. Either way the result is DoDIN APL-ready procurement for US federal, DoD, state, local, education, healthcare, and enterprise buyers, with Government Purchase Card (GPC) acceptance and FAR-based urgent and emergency acquisition support. Request a TAA-compliant quote for the C9300X-24HX-1A and a specialist will confirm compliance, price, and lead time — usually within one business day.
Can I buy the C9300X-24HX-1A as a single unit or in volume?
Both. Order a single C9300X-24HX-1A through the cart, or ask about lower pricing for volume orders, Government Purchase Card (GPC) purchases, and emergency or urgent (FAR-based) acquisitions. There is no payment up front: we confirm availability and the final total before invoicing.
Where can I find the C9300X-24HX-1A datasheet and specifications?
The official Cisco datasheet is available on this page (open the gated datasheet for the full PDF), and the Tech Specs section lists ports, power draw, dimensions, and licensing for the C9300X-24HX-1A.
Need the C9300X-24HX-1A TAA-compliant for federal or DoD?
Cisco builds this model in multiple countries, so TAA status depends on the production lot. We confirm country of origin before shipment — and if a unit isn't TAA-designated, we'll quote a TAA-certified equivalent of the same model, DoDIN APL-ready and GPC-payable.
